Characteristics ABS
The Royalite™ line of rigid thermoplastic ABS sheets offers exceptional high-heat performance, combining outstanding thermoformability with the ability to retain strength at elevated temperatures. These features make Royalite™ an excellent solution for applications requiring movement resistance or boiling water sterilization.
Royalite™ sheets are highly versatile and can be machined, sawed, drilled, routed, or ground with ease. They can also be punched, die-cut, and painted using spray, silk screen, or roller coating. For optimal results, plastics-formulated paints should be used. Additionally, these sheets can be joined to themselves or other materials using adhesive bonding, ultrasonic welding, or mechanical fasteners such as screws and rivets, provided proper procedures are followed.
Key Highlights
- Exceptional Impact Strength: High durability for demanding applications.
- High Formability: Easily thermoformed into complex shapes.
- Wide Color & Texture Options: Available in a broad spectrum of colors and textures, from smooth to deeply textured finishes.
- Versatile Finishing Options: Can be machined, sawed, drilled, routed, ground, or painted with precision.

Applications
Product | Applications | Fire & Smoke Rated | Description | Specifications |
R15 | Medical and electronic housings and components | Fire-Rated | Fire-rated ABS rigid sheet | Listed: UL 94 V-0 @ 0.060", Listed: UL 94-5VB @ 0.098" |
R24 | Office machine housings, medical. electronics | Fire-Rated | GP ABS fire-rated rigid sheet | Listed: UL 94 HB@ 0.060" |
R574 | Medical and electronic enclosures and components | Fire-Rated | Fire-rated Non-PVC, FR ABS rigid sheet | Listed: UL 94 V-0 @ 0.063", Listed: UL 94-5VA@ 0.125" |
R26 | Food handling equlpment, trays, boxes and devices | FDA- and NSF-compliant | FDA- and NSF-compllant. when requested | |
R104 | Automotive consoles, dash and door panels | Soft, vinyl foam laminated to ABS | Passes: Motor Vehicle Standard FMVSS 302 | |
R12 | Automotive houslngs and panels, food trays, tote boxes | High temperature | Heat Defleclion Temperature (HDT) = 220°F | |
R20 | Water softener housings, instrument panels. luggage | High impact, low temperature | "Notched lzod Impact (ft-lb/in) @ 70° F = 8.0 @ -30° F = 5.0 " | |
R21 | Office furniture, hospital beds, machine guards, housings, bus seating | High impact | Excellent, all-purpose thermoforming grade | |
R23 | Office or patio furniture. specialized cases | Medium impact | Excellent. all-purpose thermoforming grade |
