Characteristics PVC/Acrylic
This family of FAA-compliant sheet products offers a combination of lightweight properties, exceptional impact and tensile strength, high stiffness, and excellent formability and ductility. The reduced weight helps aircraft manufacturers lower production costs while enabling operators to reduce fuel consumption and overall operating expenses.
Key Highlights
- Lightweight: Reduces production and operational costs.
- Flame & Smoke Rated: Fully compliant with FAA standards.
- Exceptional Impact Strength: High durability for demanding applications.
- High Tensile Strength: Provides superior structural integrity.
- Excellent Formability: Easily shaped to meet design requirements.
- Extensive Color & Texture Options: Available in a wide range of colors and textures, from smooth to deep-textured finishes.
- Versatile Finishing Capabilities: Can be machined, sawed, drilled, routed, and ground with ease.
Applications
Product | Applications | Fire and Smoke Rated | Description | Specifications |
| R49/52 | Building and construction, wall protection | Fire-Rated | Fire-rated PVC/Acrylic rigid sheet | Class-A: ASTM E-84 @ 0.080", bonded to cement board |
| R52 | Medical and electronic components and enclosures: aircraft cabin and seat components: mass transit; building and construction | Fire-Rated | Fire-rated PVC/Acrylic rigid sheet | Listed: UL 94 V-0 @ 0.027" Listed: UL 94-5VA@ 0.051" Passes: FAR 25.853 (a)(I) @ 0.040" Class A: ASTM E84 @ 0.028", bonded |
| R60 | Medical and electronic components and enclosures | Fire-Rated | Fire-rated, 100% recycled PVC/Acrylic rigid sheet | Listed: UL 94 V-0 0.031" L;sted: UL 94-5VA@ 0.094" |
| R552 | Medical and electronic components and enclosures | Fire-Rated | Fire-rated, 100% recycled PVC/Acrylic rigid sheet | Listed: UL 94 V-0 0.031" L;sted: UL 94-5VA@ 0.094" |
| R60 | Aircraft cabin and seat components | Fire-Rated | Fire-rated PVC/Acrylic rigid sheet | Passes: FAR 25.853 (a)(i)@ 0.040" |
| R61 | Mass transit interiors, seats, panels | Fire-Rated, Smoke Rated | Smoke-rated, flre-rated PVC/Acrylic rigid sheet | Passes: Motor Vehicle Standard FMVSS 302 Passes: UL 94 V-0 @ 0.031"" Passes: FTA Guidelines Docket 90 |
| R86 | Outdoor equipment, electronlc and telecom enclosures | Flame-retardent | Weatherable, name-retardant, rigid PVC/Acryllc Alloy | Listed: UL 94 V-0 @ 0.028"" and above Listed: UL 94-5VA@ 0.085"" and above Passes: Motor Vehicle Standard FMVSS 302 |
| HG | Small to medium handgun holsters, knife sheaths | Holster grade sheet | Easy to form, machlne, fasten and bond; durable; range of colors and textures | |
| R52 AM | Building and construction, wall coverings, panels | Fire-Rated | Fire-rated with antimicrobial technology | Listed: UL 94 V-0 @ 0.028"" and above Listed: UL 94-5VA@ 0.118' and above Listed: UL 94-5VB@ 0.047"" and above Class-A: ASTM E84 @ 0.060"" Meets: G-22 for reslstance to bacterial growth |
Spartech Royalite™ PVC/Acrylic
